Regulation:A-Circuit
Voltage Set Point:14.5V
Soft Start 30 %
LRC 5 sec
Field Shorted Circuit Protection
IG / Sense Open Indication
Under / Over Voltage Indication
DFM Function
63.5mm Mounting
| Brand | Number |
| GPD | HN226 |
| YUNYI | 13322700/03-038 |
| WAI / TRANSPO | IN226 |
| ASE | ARE6006S |
| CQ | CQ1010261 |
| USI | 71-30004 |
| PSH | 052.000.812 |
| CARGO | 132645 |
| HUCO | 132941 |
| CASCO | CRE40124 |
| KRAUF | ARN6226 |
| DIXIE | 3546-4216 |
| SANDO | SRE40124 |
| WOODAUTO | VRG46806 |
| GHIBAUDI | RTR8059 |
| LUCAS | 21510071 |
| LUCAS | UCJ424 |
| ERA | 215655 |
| ERA | IVR-513J |
| POWERMAX | 81111506 |
| POWERMAX | 1111506 |
| UNIPOINT | YR-637 |
| UNIPOINT | YR-646 |
| MEGNETI MARELLI | 943346008010 |
| MEGNETI MARELLI | 943355175010 |
| MOBILETRON | VR-H2005-9 |
| MOBILETRON | VR-H2005-9A |
| LESTER | 13386 |
| LESTER | 13387 |
| LESTER | 14680 |
| FIT UNIT | 31100-PR7-A01 |
| FIT UNIT | 31100-PY3-003 |
| FIT UNIT | 31100-PY3-003RM |
| FIT UNIT | 31100-PY3-013 |
| FIT UNIT | CLB18 |
| DENSO | 126000-0540 |
| DENSO | 126000-1060 |
| DENSO | 126000-1170 |
| DENSO | 100211-2010 |
| DENSO | 100211-2011 |
| DENSO | 100211-2140 |
| DENSO | 100211-6150 |
| DENSO | 100211-6170 |
| DENSO | 9760211-617 |
| HONDA | 31150-PD6-004 |
| HONDA | 31150-PD6-014 |
| HONDA | 31150-PD6-024 |
| HONDA | 31150-PH3-013 |
| HONDA | 31150-PR7-A01 |
| HONDA | 31100-PD6-004 |
| HONDA | 31100-PD6-004RM |
| HONDA | 31100-PD6-014 |
| HONDA | 31100-PJ0-661 |
| HONDA | 31100-PJ0-661RM |
| HONDA | 31100-PJ0-662 |
| HONDA | 31100-PJ0-663 |
| HONDA | 31100-PJ0-663RM |
| HONDA | 31100-PY3-003 |
| HONDA | 31100-PY3-003RM |
| HONDA | 31100-PY3-013 |
| HONDA | CJK22 |
| HONDA | CJK35 |
| HONDA | CLB18 |
