Regulation:B-Circuit
Voltage Set Point：14.20V
Soft Start 32% LRC 5sec
Field,Lamp Shorted Circuit Protection
Sense Open Indication
Under Voltage Indication
Over Voltage Indication
DFMfunction
| Brand | Number |
| GPD | HN6015 |
| YUNYI | 13300700/03-069 |
| WAI / TRANSPO | IN6015 |
| WAI / TRANSPO | 107015 |
| ASE | ARE6075 |
| PSH | 052.000.091 |
| OEM | GS1M3170 |
| REAL | 20532841 |
| CARGO | 330959 |
| DIXIE | 3546-4516 |
| SANDO | SRE40148 |
| KRAUF | ARN6015 |
| CASCO | CRE40148 |
| AS-PL | UD01464ARE |
| WOODAUTO | VRG47358 |
| MOBILETRON | VR-H2005-91 |
| PAN PACIFIC | 86-117 |
| ERA | 215691 |
| ERA | IVR-5017 |
| LESTER | 11087 |
| LESTER | 11090 |
| LESTER | 11153 |
| LESTER | 11197 |
| LESTER | 11198 |
| LESTER | 11571 |
| LESTER | 13983 |
| LESTER | 13994 |
| LESTER | 23317 |
| LESTER | 24056 |
| DENSO | 0150 |
| DENSO | 126600-0150 |
| DENSO | 104210-3380 |
| DENSO | 104210-3390 |
| DENSO | 104210-3410 |
| DENSO | 104210-3411 |
| DENSO | 104210-3440 |
| DENSO | 104210-3441 |
| DENSO | 104210-3442 |
| DENSO | 104210-3460 |
| DENSO | 104210-3680 |
| DENSO | 104210-3930 |
| DENSO | 104210-4000 |
| TOYOTA | 27060-0F040 |
| TOYOTA | 27060-0F040-84 |
| TOYOTA | 27060-0F050 |
| TOYOTA | 27060-0F050-84 |
| TOYOTA | 27060-0F060 |
| TOYOTA | 27060-0F060-84 |
| TOYOTA | 27060-0F080 |
| TOYOTA | 27060-0F080-84 |
| TOYOTA | 27060-0L020 |
| TOYOTA | 27060-0L021 |
| TOYOTA | 27060-0L022 |
| TOYOTA | 27060-30050 |
| TOYOTA | 27060-30060 |
| TOYOTA | 27060-30130 |
| TOYOTA | 27060-50320 |
| TOYOTA | 27060-50320-84 |
| TOYOTA | 27060-50330 |
| TOYOTA | 27060-50340 |
| TOYOTA | 27060-50360 |
| TOYOTA | 27060-50360-84 |
| TOYOTA | 27060-50360-84 |
| TOYOTA | 270603005084 |
